2018 Manual Magnetic Heating System Film Hot Laminating Machine

FOB Reference Price:Get Latest Price
$13,000.00 - $15,000.00 / Set | 1 Set/Sets Magnetic heating system (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Packaging Type:
Case
Packaging Material:
Wood
Type:
Laminating Machine
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
FENGMING
Model Number:
YFME-720
Power:
6KW(normal is a half)
Voltage:
220/380V
Application:
Machinery & Hardware
Weight:
400kg
Automatic Grade:
Manual
Certification:
CE SGS ISO
Driven Type:
Mechanical
Dimension(L*W*H):
1870*1660*1830mm
Product name:
2017 Manual Magnetic Heating System Film Hot Laminating Machine
Max.Laminating Width:
700mm
Laminating Temperature:
60-130℃
Paper Thickness:
80-500g/㎡
Laminating Speed:
0-30m/min
Diameter of Heating Roller:
268/320mm
Diameter of Film Paper core:
≤76mm(3 inch)
Total Weight:
400kg
Mode of operation:
manual laminating machine
Function:
Wrapping Outer Paper
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
1000 Set/Sets per Quarter Manual film laminating machine
Packaging & Delivery
Packaging Details
2017 Manual Magnetic Heating System Film Hot Laminating Machine normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Port
NINGBO&SHANGHAI
Lead Time :
Shipped in 10 days after payment




Manual Magnetic Heating System Film Hot Laminating Machine

1. YFME720/920/1200 SEMI-AUTO BOPP THERMAL FILM LAMINATING MACHINE

FEATURES

Pneumatic Dividing

Oil Heating System

Gas Expanded Shaft(with Tension System)

Film Cutter and Film Puncher

Operation Plater and Date Inputting Device

Automatic hydraulic pressure (Automatic adjustment pressure )

Anti-Curve Device

Vibration Table

TECHNICAL SPECIFICATION



Model

YFME720

YFME920

YFME1200

Max.Laminating Width

680*1040mm

880*1040mm

1100*1040mm

Laminating Temperature

130

130

130

Paper Thickness

80-500g/

80-500g/M²

80-500g/M²

Laminating Speed

53m/min

53m/min

53m/min

Total power

13kw(normal is a half)

13kw(normal is a half)

13kw(normal is a half)

Voltage

220/380V

220/380V

220/380V

Diameter of Heating Roller

300mm

300mm

300mm

Diameter of Rubber Roller

240mm

240mm

240mm

Diameter of Film Paper core

76mm(3 inch)

76mm(3 inch)

76mm(3 inch)

Total Weight

1600kg

1700kg

1800kg

Overall Dimension

2750*1580*1800mm

2750*1780*1800mm

2750*2060*1800mm
