Semi-auto heat press water base laminating machine for paper A1A2A3A4 size

FOB Reference Price:Get Latest Price
$25,273.79 - $26,499.19 / Set | 1 Set/Sets laminator machine (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Packaging Type:
Case
Packaging Material:
Wood
Type:
Laminating Machine
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
FENGMING
Model Number:
YFMP1100
Power:
47KW
Voltage:
380V
Application:
Machinery & Hardware
Weight:
4300kg
Automatic Grade:
Semi-Automatic
Certification:
CE Certification
Driven Type:
Mechanical
Dimension(L*W*H):
5600mm*2250mm*2000mm
Product name:
Laminating Machine
Speed:
0-30m/min
Warranty:
1 Year
Max laminating width:
1050mm*900mm
Base Material:
BOPP film
Color:
You can decide
Paper Thickness:
100-500g/m2
Item:
Hot Roll Laminator
Mode of operation:
SEMI-automatic
Function:
Wrapping Outer Paper
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
211 Set/Sets per Year laminator machine
Packaging & Delivery
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Port
NINGBO&SHANGHAI
Lead Time :
Shipped in 35 days after payment
Product Description




Type: Laminating Machine                       Condition: new                                             Application: Machinery & Hardware



Packaging Type: Cartons                         Packaging Material: Wood                               Automatic Grade:SEMI- Automatic



Driven Type: Mechanical                           Computerized:Yes                                                   Place of Origin: Zhejiang, China



Brand Name: FENGMING                        Model Number: YFMP1100                     COLOR: YOU CAN DECIDE



Specifications



Specifications



1.suit for water base film and thermal film.
2.CE certification
3.automatic cutting



Manual Water-base Laminator and thermal film laminating machine
Application
It is used for water-base lamination and thermal film
Configuration
1. It adopts conservational water-base glue and BOPP film or PET film to laminate paper products.
2. Manual paper feeding

3. SCHNEIDER frequency converter is equipped for infinitely variable speed, and the operator can change the machine’s speed easily and guarantee the machine’s running stable.

4. Paper regulating plate can move left and right, and regulates manual paper feeding.

5. Glue supplying system supplies and recycles water-base glue automatically.

6. Dip coating saves glue and homogenizes coating much better.

7. Film cutter cuts film width to make it meet paper size. The cut film is left on the film release spindle.

8. Film perforating wheel perforates film edge for the automatic cut of laminated paper.

9. Automatic paper winder rolls up laminated paper. Winding speed is adjustable upon applications.

10. Phillip IR drying lamp is equipped for smooth working in humid and cold climate.

11. No paper protector stops the machine’s running when no paper occurs in paper conveying.

12. The winded paper is supported by a trolley, and then put on cutting machine for quick automatic cut, or cut by manual work.
13.automatic cutting and stacker.



Technical Parameter:



Model

YFMP-1100

YFMP-1200

Max laminating size

1050*900mm

1180*1100mm

Min laminating size

300*300mm

300*300mm

Max speed

30m/min

30m/min

Laminating temperature

normal-130°C

normal-130°C

Paper weight

100-500g/m2

100-500g/m2

Power

47kw

47kw

Total Weight

4300kg

5200kg

Overall Dimensions

5600*2250*2000mm

5600*2400*2000mm
